Highly sensitive devices of the DSC-60 Plus/60A Plus series are used to study the thermal properties of materials in research and quality control in areas such as the production of polymers, pharmaceuticals, electronic components, food products, etc. The standard equipment of the calorimeter includes a cooling system with liquid nitrogen, which is poured through a special hole, and allows you to do without installing special accessories (cooling efficiency is 10 °C/min at -100 °C).
DSC-60 Plus/60A Plus
Differential scanning calorimeters
In order to optimize the time of routine research and increase productivity, the DSC-60A Plus analyzer is equipped with an automatic sample changer (24 samples).
Features
- High baseline stability over the entire temperature range (from -140 to 600 ° C).
- High sensitivity (noise level less than 0.5 μW).
- By combining the furnace and the liquid nitrogen cooling system (standard equipment) in one device, the heat capacity of the furnace is significantly reduced.
- The liquid nitrogen cooling system is designed to perform measurements at temperatures below room temperature without installing additional accessories.
- The new furnace design allows you to reduce energy consumption by 20% (heating from room temperature to 300 ° C at a speed of 20 ° C / min).
- Cooling rate 35 ° C / min at 0 ° C and 10 ° C / min at -70 ° C.
- Thanks to the “sample loading temperature” function, only the area around the sample is heated when replacing the sample, so that the measurement can be quickly resumed without moisture condensation.
TA-60WS workstation
The station provides the ability to simultaneously connect and control up to 4 devices (DTG, DSC, TMA, TGA, DTA) with simultaneous data processing. The TA-60WS software has an intuitive interface and allows you to perform all the operations necessary for collecting and processing measurement results, creating reports.
Consumables (crucibles)
Aluminum, platinum, nickel, copper, quartz; sealed and non-sealed crucibles, etc.
Two additional cooling systems are possible:
- TAC-60L (Liquid Nitrogen Cooling System)
- TAC-60i (Electric Cooling System)
